3RGBLED Outdoor 2ft by 1ft FIXIII SERIES LED advertising screen
standard size 2ftx1ft
609.6×304.8x63mm
Outdoor Ultra light weight and ultra thin LED display
Cabinet thickness 63mm.
Each cabinet only 3.9KG,
includes fixed frame, total 8.9KG
Aluminum frame
Compare with traditional cabinet
2ft by 1ft LED display, one person can hold,Simple operation, save Labor cost and installation costs
Function
High Protection Aluminum LED sign
Dual service Front and rear maintenance
Easy and quick maintenance
Modular cabinet. One 2ftx1ft cabinet has one power box.
Internally integrated power supply and receiver module.
LED Sign size is more flexible
Module Beveled Edge Design, support Large corner project
Such as right angle LED screen, 90 degree LED screen
And 180degree LED screen
Build 3D LED display, DOOH LED display, Square LED screen, curve LED display
Fully sealed cabinet design, achieve Dust prevention, moisture resistance, corrosion resistance
High brightness LED display, support 8000nits, 1000nits High brightness LED sign.
4:3, 16:9 Golden Ratio, can make 1080P, 2k, 4k and 8K.
Available module: p4.76 LED display. P6.35 LED display. P9.525 LED display
Specification
| Model | Outdoor | Outdoor | Outdoor |
| Pixel Pitch(mm) | P4.76 | P6.35 | P9.525 |
| Resolution | 128×64 | 96×48 | 64×32 |
| Module size (mm) | 609.6×304.8 | 609.6×304.8 | 609.6×304.8 |
| Cabinet size(mm) | 609.6×304.8 | 609.6×304.8 | 609.6×304.8 |
| Weight(kg) | 3.9 | 3.9 | 3.9 |
| Brightness(nits) | 6500-10000 | 6500-10000 | 6500-10000 |
| Color Temperature | 2500k~10000k | 2500k~10000k | 2500k~10000k |
| Viewing Angle(H./V.) | 160°/160° | 160°/160° | 160°/160° |
| Gray Scale(Bit) | 16 | 16 | 16 |
| Fresh rate(Hz) | 1920-3840 | 1920-3840 | 1920-3840 |
| Working Voltage | AC:100V~240V | AC:100V~240V | AC:100V~240V |
| 50/60HZ | 50/60HZ | 50/60HZ | |
| Power Consumption Max(W) | 800 | 550 | 550 |
| Power Consumption AVG(W) | 260 | 180 | 180 |
| Operating Temp(℃) | -30℃～+50℃ | -30℃～+50℃ | -30℃～+50℃ |
